Clio Solar Sleek Post Top(PTSL)

All-in-one design with solar panel, light engine, and abttery built into the fixture. No need for a power source, which eliminates the need for trenching and wiring. It’s perfect for parks, city sreets, school campuses and pedestrian walkway. Engineered to perform like conventional post top lighting, Oceanside Solar post top features high-performing LEDs fueled by solar energy.

CONSTRUCTION

• All-in-one design with solar panel, light engine and battery
• Modern form design, ideal for architectural outdoor application
• Die cast aluminum housing, clear glass diffuser

PHOTOMETRICAL INFO

• 4000K/5000K
• CRI>80

SOLAR & BATTERY

•  18V/30W mono-crystalline cell solar panel, with MPPT charge controller
• 12.7V/16AH (103WH) LiFePO4 Battery, with overcharge and over-discharge protection
• 2000 charge cycles (2000/365 days=5.47 years)
• Battery charge time: 16-20 hrs*
• Max operation time: 36 hrs*

*Depend on sunlight quality

CONTROL MODE

• With pre-installed PIR sensor
• Support dusk-to-dawn lighting, step dimming with motion sensor override, and time control

APPLICATIONS

• Parks, entrance ways, walkways, driveways and other outdoor spaces.

OPERATION TEMPERATURE

• -10℃(14℉) to 50℃(122℉)

LIFESPAN & WARRANTY

• 5 year warranty, 100,000+ hrs lifetime based on LM-80 results and TM-21 calculations

LISTINGS

• IP65 rated
• IK08 Impact rated
