Open Face Thin Wall Pack G5(WPDSN)

The WPDSN DUO Selectable Classic Wall Pack series by ATG focuses on energy savings and efficient lighting solutions. Its top-of-class, space-efficient casing is made from heavy-duty die-cast aluminum housing with a glass striped lens. This fixture is ideal for a wide range of applications, including building exteriors, perimeters, pathways, stairways, tunnels, alleyways, security walls, overpasses, loading docks, security lighting, and parking garages. The compact design makes it versatile for different use cases. The WPDSN is IP65 rated for wet locations and can operate in ambient temperatures from -40º to 40ºC. Its superior material design generates higher lumens per watt, allowing it to replace higher voltage fixtures while maintaining or exceeding performance. The fixture comes in one body style with three selectable wattages and three CCT ranges for easy customization. An On/Off photocell is pre-installed, and additional options such as a microwave sensor and emergency backup are available separately. It is backed by a 10-year limited warranty.

REQUEST A QUOTE
  • Description
  • Specifications
  • Resources & Downloads
  • Q & A
  • Related Products

Description

The WPDSN DUO Selectable Classic Wall Pack series by ATG focuses on energy savings and efficient lighting solutions. Its top-of-class, space-efficient casing is made from heavy-duty die-cast aluminum housing with a glass striped lens. This fixture is ideal for a wide range of applications, including building exteriors, perimeters, pathways, stairways, tunnels, alleyways, security walls, overpasses, loading docks, security lighting, and parking garages. The compact design makes it versatile for different use cases. The WPDSN is IP65 rated for wet locations and can operate in ambient temperatures from -40º to 40ºC. Its superior material design generates higher lumens per watt, allowing it to replace higher voltage fixtures while maintaining or exceeding performance. The fixture comes in one body style with three selectable wattages and three CCT ranges for easy customization. An On/Off photocell is pre-installed, and additional options such as a microwave sensor and emergency backup are available separately. It is backed by a 10-year limited warranty.

Specifications

Input Voltage
120-277VAC
Wattage
40W/60W/80W SELECTABLE
CCT
3000K/4000K/5000K SELECTABLE
Warranty
10 Years
L70 lifetime
>50,000 Hrs
Dimming
0-10V
IP Rating
IP65
Lumens
12519 LM
Efficacy
140-158 LM/W

Resources & Downloads

product brochure
installation guide
