Archer G2 Area Light 150W DUO SELECT(AR2)

The ATG Archer is a modern and versatile area light series that comes with three robust packages all in three clean Compact low profile design delivering high-performances. High-quality finishes prevent corrosion, protects against extreme environmental conditions. Each body option comes with its own three switchable wattages ranging from 60-80-100W, 100-120-150, and 200-240-300W. The selectable CCT options are in the 3000K,4000K, and 5000K range. Heavy duty die cast aluminum housing with ample heat sinking Comes in standard Bronze Housing (custom finishes are optional) and T3 optic pre-installed. With 4 optics available in T2,T3,T4,T5, the fixture is ideal for walkways, roadways, parking lots, auto dealerships, recreational venues, and other outdoor lighting needs. Four contractor-friendly mounting options available and sold separately like the adjustable arm mount, slip fitter and wall mount are provided for different applications. Multiple Mounting, Optics, and Control options specific to applications and security types scenarios. 6KV surge protection, 347-480V are available with additional cost and lead time. Sensor receptacle pre-installed, plug-and-play occupancy sensor sold separately. Bluetooth mesh smart sensor optional. Integrated NEMA/ANSIC136.10 3-pin and 7-pin photocell optional. UL Certifed, lP 65 rated, DLC Premium V5.1 listed.

REQUEST A QUOTE
  • Description
  • Specifications
  • Resources & Downloads
  • Q & A
  • Related Products

Description

The ATG Archer is a modern and versatile area light series that comes with three robust packages all in three clean Compact low profile design delivering high-performances. High-quality finishes prevent corrosion, protects against extreme environmental conditions. Each body option comes with its own three switchable wattages ranging from 60-80-100W, 100-120-150, and 200-240-300W. The selectable CCT options are in the 3000K,4000K, and 5000K range. Heavy duty die cast aluminum housing with ample heat sinking Comes in standard Bronze Housing (custom finishes are optional) and T3 optic pre-installed. With 4 optics available in T2,T3,T4,T5, the fixture is ideal for walkways, roadways, parking lots, auto dealerships, recreational venues, and other outdoor lighting needs. Four contractor-friendly mounting options available and sold separately like the adjustable arm mount, slip fitter and wall mount are provided for different applications. Multiple Mounting, Optics, and Control options specific to applications and security types scenarios. 6KV surge protection, 347-480V are available with additional cost and lead time. Sensor receptacle pre-installed, plug-and-play occupancy sensor sold separately. Bluetooth mesh smart sensor optional. Integrated NEMA/ANSIC136.10 3-pin and 7-pin photocell optional. UL Certifed, lP 65 rated, DLC Premium V5.1 listed.

Specifications

Input Voltage
120-277VAC & 347-480VAC
Wattage
100W/120W/150W SELECTABLE
CCT
3000K/4000K/5000K SELECTABLE
Warranty
10 Years
L70 lifetime
>50,000 Hrs
Dimming
0-10V
IP Rating
IP65
Lumens
24101 LM
Efficacy
124-163 LM/W
Lens Type
Type II/Type III/Type IV/Type V
